Intraparotid facial nerve schwannoma: two case reports and a review of the literature| ACTA Otorhinolaryngologica Italica

Abstract

Schwannomas are rare benign tumours that arise from Schwann cells. The most known and studied is the intracranial vestibular schwannoma,
even if it is not the most frequent. More often schwannomas arise from peripheral sensitive nerves, and the vagous is most involved
among the cranial nerves. Intraparotid schwannomas account for just 10% of all facial involvement, so they are an extremely rare localisation.
At present, there are less than 100 cases described in the literature. We performed a retrospective analysis of parotidectomy in two
Italian hospitals and present two cases of intraparotid schwannoma and a review of the literature. In the first case, we performed a parotidectomy
with a stripping of tumour from the nerve. In the other case, a hypoglossal-facial neurorrhaphy was performed. Follow-up was 24
months in the first (House-Brackmann II degree in temporal-ocular and III in facial-cervical branches) and 30 months in the second case
(House-Brackmann III degree in both temporal-ocular and facial-cervical branches). Preoperative diagnosis of facial nerve schwannoma is
a challenge; however, it is extremely important since post-operative palsy is common and often higher grade. Unfortunately, schwannoma
has similar radiologic finding as more common pleomorphic adenoma and often FNAC is not helpful. Due to its rarity and benign nature,
there is debate in the literature on the need for surgical removal. Wait-and-see is a valid option, but may could give problems in secondary
surgery. Stripping or near-total removal can be useful in cases of limited involvement of the nerve. Neurorrhaphy can provide good functional
results when facial sacrifice is needed.

Introduction

Schwannomas are very rare benign tumours that arise from the Schwann cells which form the sheath of peripheral nerves.

Schwannomas have no sex preference, in the literature there are studies with both female ¹ and male prevalence ².

Although the most studied and known schwannoma is intra-cranial vestibular, it is not the most frequently involved nerve. More often schwannomas arise from sensitive peripheral nerves, and the vagous is most involved among the cranial nerves. The parapharyngeal space is the most common head and neck site of occurrence ^2-4.

A facial nerve schwannoma is very rare and normally grows from the intratemporal portion of the nerve. Intraparotid facial schwannoma account for just 10% of all cases of facial involvement, and so it is an extremely rare localisation. To our knowledge, less than 100 cases of intraparotid facial nerve schwannomas have been reported in the scientific literature.

Herein, we present two cases of intraparotid schwannoma, one in a 39-year-old woman and the other in a 45-year-old man, extracted from the clinical records of two otorhinolaryngology departments (San Giovanni Addolorata Hospital in Rome and Garibaldi Hospital in Palermo). We also review the literature on preoperative signs, surgical management and outcomes.

Case reports

1st case

A 39-year-old woman came to our ENT clinic with an asymptomatic parotid mass that appeared 2 years before and grew slowly. In the last 2 months, she started to feel a dull facial pain, but no signs of facial palsy. She had two FNAC (both undiagnosed), ultrasound and an MRI (mass rising from the deep portion of parotid, isointense in T1 image and hyperintense in T2-weighted without clear diagnostic indications) (Figs. 1, 2).

At parotidectomy, we found a tumour involving the facial nerve trunk near its division into the two main branches with an atypical aspect of multilobular soft and encapsulated mass, similar to a lipoma. We dissected the tumour from the facial nerve, helped by loupe magnification (3.5x), attempting to preserve as many fibres as possible and performed surgical excision as a neural unsheathing (Figs. 3, 4).

At the end of the surgical procedure, we verified neural functions by a needle neurostimulator using 1.2 μV of electrical tension with complete but weaker facial contraction (demonstrating an integrity of the facial nerve even if its structure was not completely preserved).

Post-operative histology found an “ancient schwannoma” with cystic and haemorrhagic areas and perivascular hyalinisation; immunophenotype: vimentin+, S100+, CD34- and actin-.

At post-operative Day 1, the patient had a House-Brackmann grade IV palsy and after rehabilitation and medical therapy at 24 months follow-up she had grade II-III HB.

2nd case

A 45-years-old man in good health came to our clinic with a left parotid mass that had appeared 3 years prior and slowly increased in volume. The mass was soft and elastic at palpation, not fixed on the skin or deep plane and not painful. No facial deficit was found.

The patient had a FNAC positive for fibromixoid tissue and a contrast medium CT (bulky mass arising from the deep portion of left parotid without enhancement after contrast medium) (Figs. 5, 6).

At parotidectomy, we found a multilobular and encapsulated mass involving the facial nerve at its exit from the stylo-mastoid foramen until the division into the main branches. Unfortunately, we could not dissect the tumour without the sacrifice of the facial nerve so we performed hypoglossal-facial neurorrhaphy.

Post-operative histology founded a neuroma (immunophenotype: vimentin+, S100+, CD34- and actin-).

On post-operative Day 1, the patient had House-Brackmann grade V palsy, whereas at 30-month-follow-up, after rehabilitation and medical therapy, this was HB grade III.

Discussion

An intraparotid facial schwannoma is extremely rare tumour. In a retrospective study (2004), Caughey et al ⁵ reviewed 3722 patients in a tertiary referral centre (Shadyside Facial Paralysis Center in Pittsburgh) finding only 29 (18 women and 11 men; 0.78%) patients with facial schwannomas. Among these only 8 cases (27.5% of facial schwannomas and 0.21% of the entire cohort) had an intraparotid localisation.

In another study focused on extracranial schwannomas, Kang et al. ³ found only 4 cases of intraparotid localisation in 22 patients with cranial nerve schwannomas over a 10 year personal review.

Similarly, in a series of 113 nerve sheath tumours of the head and neck, Tabriz et al. found only 7 (6%) cases of intraparotid schwannoma ⁶.

Normally, the intraparotid facial nerve schwannoma is characterised by an intraglandular longstanding mass without specific symptoms and a low growth rate ^{5 7}. At physical examination, it appears as a painless mass with increased but soft consistency and well-defined margins. A functional deficit of the facial nerve is rarely observed. In cases in which it is, it would be more often over a longtime and with a large mass ^{5 8 9}. Facial pain is observed on occasion.

Preoperative diagnosis of facial nerve schwannoma is a major challenge. However, it is extremely important since post-operative palsy is common and often of higher grade (IV or higher in House-Brackmann scale).

Unfortunately, schwannomas have similar radiologic signs to more common parotid tumours, among which pleomorphic adenoma is the most common. At MRI, they usually show an isointensity to muscle in T1-weighted and hyperintensity in T2-weighted image with well defined margins. In contrast enhanced scans they show heterogeneous enhancement due to more cellular Antoni A parts mixed with the more mixoid Antoni B. Moreover, in “ancient schwannoma” type (as in our case), the tumour can present with degenerative changes typified by perivascular hyalinisation, calcification, cystic necrosis, relative loss of Antoni type A tissue and degenerative nuclei that may be misinterpreted as sarcomatous pleomorphisms ^10-13.

In a retrospective analysis of 5 cases of extratemporal facial nerve schwannomas, Shimizu et al. reported, as radiological signs of suspicion, tumour growth toward the facial canal and the presence of a “target sign” (peripheral hyperintensity with central hypointensity), corresponding to more cellular Antoni A type in central regions and more myxoid Antoni B peripherally ¹⁰.

In another study, Banks analysed the target sign, reporting its validity to identify the PNSTs (peripheral nerve sheath tumours), but were not able to distinguish a benign from malignant one ¹⁴.

In the same way, FNAC is of little help. In most cases, cytology is non-specific and non-diagnostic; or worse it can give a misleading diagnosis of more common pleomorphic adenoma or suspected a malignant tumour ^{3 12 14-18}.

All these make treatment of this tumour very challenging because diagnosis is often intra-operative. Moreover, there is still debate on the relevance of surgical removal since radical surgery leads to facial nerve deficit.

The same group of authors suggest a decision-making algorithm ¹⁹ based on a previous proposed classification ⁹ of facial nerve schwannomas. They recognise four kinds of schwannoma presentations: type A and B (the tumour grows on the neural edge or involves a peripheral nerve branch), type C (the tumour grows around the nerve involving it completely at the main branch or trunk) and D (the tumour grows around the nerve involving both main branch and trunk). If the patient has a type A or B tumour or pre-operative House-Brackmann grade IV or worst, the authors propose radical resection with nerve reconstruction. Otherwise, with a type C or D tumour or preserved nerve function (HB III or less grade), they avoid resection and suggest only biopsy to rule out malignancy ¹⁹.

Other authors have also proposed intra-operative biopsy to obtain diagnosis and then manage it conservatively ²⁰.

This could be a good algorithm, but one point needs deeper discussion: frozen sections of a malignant peripheral sheath nerve tumour may not be diagnosed due to inexperience of the pathologist or to inappropriateness of the intra-operative biopsy. Moreover, frozen section can lead to misinterpreting a schwannoma as a sarcoma, leading to a unnecessary radical surgery ⁸.

Thus, the assumption on what the surgical choice should based on can be, in same cases, unreliable.

Moreover, it is more difficult to perform a conservative approach to the facial nerve after first surgery with a mass biopsy, due to post-surgical fibrosis as in relapses of a pleomorphic adenoma.

Other authors suggest a “stripping microscopic surgery” or a “subtotal surgery” to remove the mass of schwannoma from the facial nerve while preserving the neural continuity without functional deficit (Lee et al. in their series had preservation of facial nerve function in all their 6 cases) ^{21 22}.

In a more recent paper Rigante et al. ²³, propose intracapsular enucleation under microscopic vision. They made a longitudinal epineurium incision on the schwannoma body and gently blunt dissected the neural fascicles from the tumour under microscopic magnification. They report a post-operative facial nerve deficit of IV on the HB scale, which improved after three months of medical and physical rehabilitation (reaching II-III).

We agree with these authors. In fact, as schwannomas arise from Schwan cells (the peripheral sheath of the nerve), theoretically radical dissection can be obtained by removing the nerve sheath along with the mass, in a process similar to “acute demyelination”. Probably this can explain our observation of more weak contraction of facial muscles at stimulation after tumour removal and the need for higher electrical tension to stimulate the nerve (1.2 μV isn’t normally used on nude nerves).

This could achieve a radical resection with nerve function recovery by new myelination of axons. This procedure would require, however, careful dissection of the mass from the nerve without lesion to the axons; moreover, the re-myelination may not be complete a remaining a partial facial deficit.

Thus, we would suggest such a procedure only in limited involvement of nerve branches or the main trunk (as in our case), so the rate of a axonal lesion is very low and the portion of unsheathed nerve is small.

In this way, radical dissection of the mass can be performed, even in type C schwannoma (by Marchioni classification) in cases with a limited extension of nerve involvement (we suggest 1 cm or less).

In all other cases, we would suggest subtotal surgery (considering the exceptionality of malignant transformation of solitary schwannomas) ³ or MRI annual follow-up avoiding surgery in agreement with Alicandri-Ciufelli et al. ¹⁹.

Conclusions

Intraparotid schwannomas are a rare entity. Pre-operative diagnosis is difficult despite FNAC and radiological investigation, and most often diagnosis is intra-operative.

The gold standard management is radical surgery with preservation of acceptable neural function, which can be obtained in almost 50% of cases. In other cases, a reasonable approach is wait-and-see, with strict clinical and radiological follow-up. However, an alternative approach has also a place in management, i.e. microscopic or loupes magnification surgery (for limited involvement of nerve) or subtotal surgery (due to the extremely rare malignant transformation) which can achieve good functional results.

Figures and tables

Fig. 1.Axial MRI scan: A) T2 FrFSE (Fast Relaxation Fast Spin Echo), B) FrFSE FAT SAT (Fast Relaxation Fast Spin Echo Fat Saturation) and C) T1 with contrast medium. In all scans the arrows show a mass with more cellular central portion (with a good enhancement after contrast medium) opposite to a more mixoid peripheral component.

Fig. 2.Coronal MRI scans: A) T2 FrFSE (Fast Relaxation Fast Spin Echo) and B) T1 with contrast medium. In both scans the arrows show, as in previous figure, a more cellular central portion opposite to a more mixoid peripheral portion mass. In this scan, we also observe the relatively proximity of the mass to the stylomastoid foramen even if there isn’t invasion of the Fallopian canal.

Fig. 3.The facial nerve at its main trunk with yellowish and soft mass partially dissected from the nerve, but still adhering to it.

Fig. 4.The facial nerve at its main trunk after radical dissection. The integrity of the nerve is achieved by unsheathed dissection.

Fig. 5.Axial CT scan with contrast medium. The arrows show the schwannoma growth in deep gland portion that goes upward under the mastoid tip (A scan).

Fig. 6.Coronal CT scan with contrast medium. The arrows in the A and B scan show the mass growth toward the stylo-mastoid foramen, which is more evident in last scan (arrow head in C scan).
