Abstract

Odontogenic sinusitis represents by definition a border condition between otolaryngology and dental science and, from a holistic perspective, cannot be managed without a proficuous collaboration between specialists. This review focus on the different scenarios currently considered by international literature as related to odontogenic sinusitis and sinonasal complications of dental disease or treatment. Consequently, this review will cover all paranasal sinuses infections caused not only by dental disease (e.g. periodontitis and caries), but also by dental procedures (extractions, endodontics and the like), implantological procedures, pre-implantological (maxillary sinus grafting) and medication-related osteonecrosis of the jaw. After dealing with the odontogenic sinusitis diagnostic process and general principles of treatment, we will thoroughly cover odontogenic sinusitis scenarios treatment following an aetiology-based approach. This literature review shows that, albeit more prospective and rigorous studies are badly needed for determining the best treatment for each patient affected by odontogenic sinusitis, the sheer variety of scenarios that may be encountered should be enough to encourage mutual collaboration between ENTs and dentist. Such collaboration is required both to perfect diagnostic and treatment and to provide

Introduction

Since it was first described in the Forties, odontogenic sinusitis (ODS) has represented a common ground for otolaryngologists and dental surgeons ¹.

ODS is far from being the only condition where otolaryngology meets with other specialities, but it is somehow unique in this duality. Where most multidisciplinary teams are usually required for treatment, properly trained specialists should also cooperate for diagnosis ².

No single specialist is usually capable of both correctly diagnosing an inflammatory process of the paranasal sinuses, adequately calibrating the tools recommended by international consensus ^3,4, and evaluating the status of teeth and dental prosthetics alike, especially given the high complexity rate the latter achieved in the last decade ⁵.

Despite the term ODS referring literally to the inflammatory process of the paranasal sinuses due to diseased teeth, as in the first description of the condition, contemporary scientific literature stretched the term to include other loosely related causes ⁶. As a result, ODS covers all paranasal sinuses infections caused not only by dental disease (e.g. periodontitis and caries) but also by dental procedures (extractions, endodontics and the like), implantological procedures, pre-implantological maxillary sinus grafting and medication-related osteonecrosis of the jaw (MRONJ). A composite figure, therefore, emerges, where a complex interplay between otolaryngologists and dental surgeons becomes most often mandatory to understand the bigger picture and correctly manage the patient.

ODS management becomes even more peculiar if we take into account that this protean group of sinonasal conditions lacks shared definition and diagnosis guidelines and the robust literature on the subject is plagued by extreme heterogeneity in defining cases and reporting outcomes. It has to be noted though that, despite guidelines on rhinosinusitis being extremely vague on this subject ³, ODS is almost universally considered a completely different condition from rhinosinusitis (RS), both in its acute and chronic forms, in terms of pathogenesis, microbiology and response to treatments ^7,8.

A recent multidisciplinary consensus statement ⁹ addressed some issues in ODS management after careful revision of scientific literature. The shared statement emerging from the modified Delphi method consensus are resume in Table I and will be further integrated in the following sections of this review.

The most complete existing classification of ODS, defined as the group of sinonasal complications resulting from dental disease or treatment (SCDDT), has been proposed by our group in 2013 ¹⁰, and has been prospectively validated ¹¹ and adopted by other groups, both nationally and internationally ^12,13. The classification (reported in Table II along with the number of patients treated at our institution from 2012 onwards) successfully tries to integrate different etiologies and possible (often multidisciplinary) treatments for possible ODS scenarios. In this review, after dealing with ODS diagnostic process and general principles of treatment, we will thoroughly cover ODS treatment following a similar aetiology-based approach: diagnosis of ODS; general principles of ODS treatment; ODS resulting from dental disease or dental treatments; ODS following maxillary sinus grafting; ODS following dental implants placement; ODS during medication-related osteonecrosis of the jaw (MRONJ).

Review

Diagnosis of ODS

As a recent systematic review of ODS literature confirmed ⁶, studies on the subject are hindered by the general lack of a diagnostic consensus. While RS diagnosis requires symptoms to be confirmed ^3,4,14, many studies diagnose ODS only on the basis of radiological and, less frequently, endoscopic signs only ⁶. Furthermore, not all authors agree on which etiologic scenarios to include under the term ODS (and even on whether or not the term ODS should be used at all). Therefore it seems licit to include until further notice all the aforementioned etiologies. The strong recommendation emerging from the literature ⁷ is that both sinusitis AND the odontogenic focus need to be identified for a correct diagnosis of ODS. Consequently, a strict collaboration between the ENT surgeon and an oral surgery specialist is strongly recommended in order to combine the expertise required to avoid ODS overdiagnosis (blatantly inducing consequent overtreatment) and underdiagnosis (which is a known frequent cause of treatment failures in sinus surgery) (Fig. 1) ^15,16. While the clinical examination, both dental and otolaryngological, is straightforward, and the use of nasal endoscopy mandatory, the choice of imaging exams is more complex. Computed tomography (CT) and cone-beam CT (CBCT) are both commonly used for diagnosing sinusitis and identifying the dental problem ^17,18, albeit with different peculiarities (as a general rule, standard CT scan provide a better resolution and contrast for the sinonasal cavities and a better visualization of soft tissues alike, while CBCTs – which represent nevertheless a continuously evolving technology – usually allow for easier diagnosis of dental conditions). However, dental specialists may further require employing techniques such as orthopantomography and periapical radiographs to complete the dental study. Such examination should surely be ordered only by the dental surgeon in selected cases, as not to expose the patient to unnecessary radiation.

General principles of ODS treatment

While it is almost impossible to cover in this review any single clinical picture and the grey areas in between in the galaxy of ODS, there are several general principles that should be taken into account when dealing with this group of conditions, some of which are also reported in Craig and colleagues’ statement ⁹.

Patient with limited sinusitis symptoms and dental pathology amenable to conservative treatment should seek dental treatment, with endoscopic sinus surgery reserved for non-healing or relapsing patients. On the other hand, patients with severe symptoms or orbital/intracranial complications should be treated with a combined approach right from the diagnosis, thus allowing for sinus drainage and resolution of the etiological dental focus.

While endoscopic sinus surgery has an undebated role in ODS treatment, the extent of said surgery is still a matter of debate, since some authors ^19,20 proposed that middle antrostomy is enough to warrant patient healing. While prospective validation of these approaches is required, at present opening all sinuses involved in ODS ^21-23, while being the most frequent approach, is recommended only in case of ODS with orbital or intracranial complications ⁹. Again, opening the maxillary sinus together with the anterior ethmoid, which represents another frequently adopted surgical choice aimed at restoring a good osteomeatal complex patency, needs further prospective validation before entering routine clinical use.

Last, before delving into the specific etiological pictures, it seems reasonable to raise a warning to the ENT specialist dealing with ODS, a warning that may sound redundant to specialists used to approach this condition. While ODS may appear as a “simpler” version of RS, where the aetiology can be rapidly identified without resourcing to endotypes and interleukin-mediated inflammatory responses, the interplay between teeth and sinuses is extremely complex, and dental causes are often elusive or uncertain. Furthermore, teeth represent an irreplaceable health asset for patients, while dental and/or implantological treatments impose hefty financial and healthcare costs, so any dental procedure, avulsions first and foremost, have to be supported by case-specific clinical evidence. Following these considerations, the statement “a shared decision-making process between the otolaryngologist, dental provider, and patient, where the benefits and risks of dental treatment and endoscopic sinus surgery (ESS) are discussed” opening Craig and colleagues’ consensus ⁹ should become a mantra in treating ODS, not to turn the ENT-dentist dialogue into a dangerous Mexican standoff with the patient.

ODS resulting from dental disease or dental treatments

The most classic aetiology of ODS represents, at the same time, the widest and most diverse chapter to explore. Among dental conditions capable of inducing sinusitis it is worth citing periapical infections, caries-related tooth decay, unerupted teeth (Fig. 2) and odontogenic cysts infections; classic dental treatments which may lead to ODS are represented by failed endodontic treatments (either incomplete or overflowing into the sinus) and extractions (resulting in either oro-antral communications – OAC – or displacement of tooth/dental fragments/dental tools fragments into the sinonasal complex) ^12,24.

While cases pertaining to this aetiology may appear extremely varied in presentation and sinus involvement, there are several standpoints than can help the collaboration between otolaryngologist and dental surgeon.

A simple but nevertheless fundamental distinction is between patients with and without OAC (Fig. 3), as originally proposed by Felisati et al. ¹⁰. The former tend to uniformly require a combined approach for OAC closure and sinus drainage, that yields its best results when performed during the same surgical session ^25,26. The same principle applies whenever an iatrogenic OAC formation is expected during ODS treatment (e.g. when the dental surgeon planned the extraction of a tooth with roots extending into the maxillary sinus or when a large odontogenic cyst requires an intraoral approach for its removal). Also, in these cases, a combined intraoral-endonasal approach should be preferred.

Patient without OAC or where an iatrogenic OAC is not expected can be managed with ESS alone. In these cases, the dental treatment can be performed during a different surgical session, which should precede ESS in low to mild symptomatic patients and follow ESS in heavily symptomatic patients ⁹.

ODS following maxillary sinus grafting

Maxillary sinus grafting (MSG) is a common pre-implantologic procedure which gained increasing popularity from the mid-eighties in patients lacking enough vertical bone height to warrant safe dental implant positioning. The procedure aims at promoting osteoinduction and osteoconduction by positioning grafts (ranging from autologous bone to hydroxyapatite) underlying the maxillary sinus Schneiderian membrane from an intraoral approach. Implant placement might be immediate or delayed, i.e. following the consolidation of the newly formed bone, according to the initial bone vertical height before grafting. Immediate implant placement can be proposed only if the initial vertical bone height is enough to warrant implant stability, with the graft providing only a further reinforcement). Sinus complications may follow MSG mainly because of Schneiderian membrane perforation during the grafting, with consequent migration of the graft inside the sinus, or due to the unnoticed presence of otolaryngological contraindications to grafting. Given the significant disruption of the maxillary sinus homeostasis ensuing the sinus floor elevation, some authors postulated that a healthy sinus, with a patent ostium and efficient mucociliary clearance, was a basic requirement for avoiding sinusitis processes ^27,28. While the collaboration between otolaryngologist and dental surgeons in evaluating candidates to MSG in order to minimize complications is almost mandatory, this topic goes beyond the scope of this chapter (see also ²⁹). Nevertheless, treating ODS ensuing MSG is another matter of strict cooperation between these specialists. To navigate this scenario and evaluate the requirement of combined approaches, several points must be taken into account: 1) dislocation of grafting material into the sinus; 2) development of a sinusitis process; and 3) the presence of an OAC.

First and foremost, if an acute infection follows MSG, appropriate imaging should be used to identify whether the grafting dislocated into the sinus. If the graft is still confined under the Schneiderian membrane, it will be up to the dental specialist to follow specific post grafting guidelines counselling whether trying to salvage the graft with appropriate antibiotic therapy or removing it via the same oral approach used when performing the MSG ²⁷. If the graft is displaced into the sinus, neither the oral approach nor nasal endoscopy is single-handedly enough to remove all the particles. In these patients, a combined approach is mandatory, with a wide antrostomy and oral access allowing the use of angled scopes and curved instruments to ventilate the sinus and remove the particles (Fig. 4). In our experience, a thorough particle removal, pivotal in maximizing therapeutic success rates in these patients, can be achieved only employing scopes and instruments both through the nose and the oral access, in order to allow the best maxillary sinus visualization ³⁰.

Secondly, the specialist should investigate whether a sinus inflammatory process has taken place, with careful clinical evaluation of the patient coupled with endoscopy and/or appropriate imaging. Even in the few cases where sinusitis ensues MSG but without graft infection and displacement (e.g. if the sinusitis ensues months after the grafting, leaving enough time for osseointegration), an endoscopic endonasal approach is required to open the ostiomeatal complex and ventilate the sinus. As a general rule, if the graft is not displaced into the sinus, oral access for graft removal is not required.

Last, the presence of residual OAC communication must be properly evaluated also in post-MSG patients. A residual OAC, which often appears in correspondence to the bony window used for grafting, makes an intraoral approached closure mandatory.

ODS following dental implants placement

ODS may follow implants placement going awry for three main reasons: 1) implants may lose (or never achieve at all) osseointegration and dislocate into the mouth/sinuses leaving an OAC behind; 2) implants may dislocate into the sinuses, sometimes leading also to sinusitis, or 3) implants may develop peri-implant osteitis (or peri-implantitis) and act as a Trojan horse in allowing bacteria to reach the otherwise sterile sinusal spaces ³¹.

The first scenario requires a combined approach were sinus drainage is achieved endoscopically and OAC closure is performed transorally. Implants displaced into the sinuses may be retrieved either transorally or via nasal endoscopy according to position and surgeons’ preference.

The second scenario, sinusal implant displacement, must be treated endoscopically in case of sinusitis, draining sinuses and removing the implant. In case of implant displacement without sinusitis, the retrieval can be performed either transorally, via a bony window or canine fossa access, or endoscopically ^32,33.

Cases in which dental implants are, at least apparently, osseointegrated require the most careful planning and diagnostic workup (Fig. 5). While multidisciplinary statements suggest primary endoscopic surgery aimed at treating the patient without removing the implant ⁹, the surgeon must take into account that failure to recognize an unstable and infected implant is a frequent cause of treatment failure ^10,34,35. Indeed, unnecessary implant removal might enhance the risk of OAC and inevitably burdens patients with further oral rehabilitation costs. Intraoral radiographs, orthopantomography and careful dental clinical evaluation can help in minimizing risks at both ends of the spectrum, though only sharing the diagnostic and therapeutic plan with the patient allows tailoring the treatment. In these patients, multidisciplinary collaboration represents more of a diagnostic need than a therapeutic tool. For the sake of completion, it has to be noted that implant penetration in the maxillary sinus is not per se an indication to implant removal and does not necessarily imply the development of a sinusitic process over time ³⁶.

ODS during medication-related osteonecrosis of the jaw (MRONJ)

OS following MRONJ is maybe the least studied scenario hereby presented, and the only scenario which is actually falling outside of Felisati classification ¹⁰. Only three international groups presented MRONJ-related ODS cases in their series ^12,37,38. For these patients, intraoral access is recommended for removing necrotic bone ¹² and should be coupled with an adequately calibrated antrostomy in order to explore, drain and ventilate the sinus removing any further foreign body ^37,38. While the cooperation with an oral surgeon seems based on solid scientific premises, MRONJ-related ODS requires at present further exploration to enhance patients’ treatment.

Conclusions

ODS represent, by definition, a border condition between otolaryngology and dental science and, from a holistic perspective, cannot be managed without a proficuous collaboration between specialists.

Albeit more prospective and rigorous studies are badly needed for determining the best treatment for each patient, the sheer variety of scenarios that may be encountered should be enough to encourage mutual collaboration between ENTs and dentists, both for perfecting diagnostic and treatments and providing a solid scientific and medico-legal foundation for each intervention proposed to patients.

Figures and tables

Figure 1.Sagittal CT image showing an odontogenic cyst extending into the body of the sphenoid sinus. Odontogenic sinonasal pathology could represent a matter of difficult differential diagnosis in some patients. A strict collaboration between otolaryngologist and dental specialist is often therefore required also in diagnostic terms.

Figure 2.Coronal CT image showing unerupted teeth which determined a sinusitis process involving the ipsilateral maxillary sinus, ostiomeatal complex and, partially, anterior ethmoid sinus. Furthermore, the infection progressively led to the formation of oro-antral communication. A combined approach was performed in order to drain and ventilate the involved sinuses via an endoscopic approach and to remove the unerupted teeth and close the oro-antral communication from an intraoral approach.

Figure 3.Intraoperative photograph of oroantral communication. A vestibular Rehrmann flap has been raised in order to provide a tension-free closure of the communication.

Figure 4.Endoscopic view of the right maxillary sinus obtained via a trans alveolar approach. A combined approach, both in operative and visualization terms, is required in post maxillary sinus grafting patients in order to completely remove the displaced and infected grafting material, in this specific case along with a non-osseointegrated implant.

Figure 5.Intraoperative photograph showing the removal of an unstable dental fixture which developed a severe peri-implant infection, leading to sinusitis, in a patient with multiple infected implants.
