Sclerotherapy with polidocanol microfoam in head and neck venous and lymphatic malformations
Abstract
Objective. Polidocanol sclerotherapy of head and neck venous malformations (VMs) and lymphatic malformations (LMs) has been reported only in limited series. In this manuscript we evaluated the efficacy and safety of polidocanol sclerotherapy in a series of head and neck venous and lymphatic malformations.
Methods. This retrospective observational study analysed data on 20 head and neck VMs and LMs that underwent to percutaneous or endoscopic intra-lesional 3% polidocanol microfoam sclerotherapy at our institution. Clinical response was ranked as excellent, moderate and poor based on volume reduction by MRI and resolution of symptoms.
Results. The median volume decreased from 19.3 mL to 5.8 mL after sclerotherapy (mean volume reduction: 72.98 ± 16.1%). An excellent-moderate response was observed in 94.4% of cases. We observed a mean volume reduction of 79.5 ± 16.1 in macrocystic LMs, of 76.1 ± 13.0% in VMs, of 60.5 ± 10.9% in mixed lymphatic ones and 42.5% in microcystic lymphatic ones.
Conclusions. Polidocanol sclerotherapy appears to be an effective and safe treatment for venous and lymphatic head and neck malformations. We observed the best responses in macrocystic LMs and VMs, whereas mixed lymphatic ones showed a moderate response and microcystic lymphatic ones a poor response.
Introduction
Venous and lymphatic malformations are heterogeneous group of pathologies characterised by morpho-structural and/or functional alterations that can affect any type of blood and/or lymphatic vessel of any calibre or anatomical district 1. The classification of International Society for the Study of Vascular Anomalies (ISSVA) 2 is commonly used and subdivides vascular anomalies into two main groups: vascular tumours and vascular malformations 3. The latter group encloses high-flow lesions (arteriovenous malformations and arteriovenous fistula) and low-flow ones, including venous and lymphatic malformations.
Venous malformations (VMs) account for 44-64% of all vascular malformations, with an incidence in the general population between 0.8%-1% 4. About 40% of VMs affect head and neck region 5. Lymphatic malformations (LMs) result from embryogenetic defects of lymphangiogenesis and 75% of cases are localised in the head and neck region and may result in functional and aesthetic deficits that may have a negative psychosocial impact, particularly if untreated 6.
The optimal paradigm for management of venous and lymphatic malformations has yet to be established. Management strategies include “wait and see” with medical treatment of exacerbations, sclerotherapy, or surgical resection. From a clinical point of view, it is very useful to distinguish between high-flow and low-flow vascular malformations in order to determine the most appropriate treatment strategy. In fact, percutaneous sclerotherapy, which is not generally indicated for high-flow lesions, has become a popular alternative to surgical treatment for low-flow vascular malformations 7. De Maria et al. recently confirmed in a meta-analysis that percutaneous sclerotherapy is a very safe and effective modality for treatment of VMs of the head, neck and face 8.
To date, several different agents have been proposed for sclerotherapy with variable rates of efficacy. Ethanol, although one the first sclerosing agents used for vascular malformations, is rarely chosen today due to its substantial side effects, such as skin complications (necrosis, pain and blistering), peripheral nerve injury, respiratory depression, cardiac arrhythmia, seizure, rhabdomyolysis and hypoglycaemia 9. In a review in 2016, Horbach et al. reported that the rate of complications was higher after ethanol sclerotherapy (18%) compared to other sclerosing agents (0-6%) 7.
As an alternative OK-432 (lyophilised mixture of Streptococcus pyogenes and benzylpenicillin) has been used to treat successfully mainly macrocystic lymphatic malformations 10. Bleomycin, initially developed as an anti-tumour agent, has been used in the treatment of both microcystic and macrocystic LMs 11. Finally, doxycycline, a broad-spectrum antibiotic, has been demonstrated to be safe and effective in managing head and neck macrocystic and mixed LMs 12.
Polidocanol (hydroxy-polyethoxy-dodecane - POL), a synthetic long-chain fatty alcohol, is a liquid surfactant with endothelial cytolytic properties and has mainly been used for venous malformations. Polidocanol injection is painless, does not induce necrosis if injected intradermally and rarely produces allergic or inflammatory reactions 13-17. Recently, it has also been proposed for lymphatic ones even though it has been investigated in only a limited number of studies based on small samples, including several sites and not focused only on head and neck cases 14,17,18.
Herein, we report our protocol for head and neck lesions describing our endoscopic and percutaneous approaches that are performed in close cooperation between an interventional radiologist and ENT surgeon. Specifically, the objective of this study was to analyse the efficacy and safety of polidocanol sclerotherapy for head and neck vascular malformations in term of volume reduction at MRI and resolution of symptoms at clinical evaluation.
Materials and methods
Study population and study design
This is a non-profit retrospective observational study performed at a single institution. Inclusion criteria were: patients treated by sclerotherapy at our institution because of symptoms (dysphagia, dyspnoea, pain), aesthetic concerns with a negative psychosocial impact, oncoming risk of airway obstruction, increasing volume at radiological follow-up. Exclusion criteria were: high flow vascular malformations, previous surgery or previous sclerotherapy for the lesion to treat. Based on inclusion and exclusion criteria, we analysed data on 23 consecutive patients with head and neck vascular malformations who were diagnosed, treated and followed at our institution between January 2016 and November 2019. Three patients were excluded: one oral arteriovenous malformation treated with angiographic embolisation; two life-threatening mixed giant lymphatic congenital malformations requiring surgery (the first treated with surgery and sirolimus; the second with sclerotherapy with OK-432–Picibanil, surgery and medical therapy with sirolimus).
LMs were categorised based on cyst dimension as follows: macrocystic (M > 50% of cysts larger than 2 cm), mixed (mix, < 50% of cysts larger than 2 cm) and microcystic (m, all cysts smaller than 2 cm) 19. They were classified according to the de Serres staging system 20: stage I (unilateral infrahyoid disease), stage II (unilateral suprahyoid disease), stage III (unilateral infrahyoid and suprahyoid disease), stage IV (bilateral infrahyoid disease) and stage V (bilateral infrahyoid and suprahyoid disease).
The data were directly obtained from our computerised clinical database and medical records. Informed consent about privacy and utilisation of clinical data was obtained from patients at the time of original data collection. The data were anonymously analysed. The following data were taken into consideration: symptoms, site of malformations, clinical objective characteristics of the lesions at ENT physical evaluation, videolaryngoscopy, pre-treatment magnetic resonance imaging (MRI) features, treatment modalities and complications. Finally, we analysed outcomes at 6-months in terms of resolution of symptoms and reduction of radiological volume at MRI.
Clinical management
In our clinical practice, candidates for sclerotherapy usually undergo pre-operative clinical examination, endoscopy of the upper airways and MRI. We usually discuss each case with an expert head and neck radiologist to confirm the diagnosis, characterising the type, site and extension of the lesion before treatment. All this information is particularly important for adequate counselling and treatment planning. We usually suggest sclerotherapy in case of symptoms (dysphagia, dyspnoea, pain), aesthetic concerns with a negative psychosocial impact and poor quality of life, oncoming risk of airway obstruction and increasing volume at radiological follow-up. Sclerotherapy is generally performed on outpatients unless involvement of the upper airways requires general anaesthesia and overnight observation. Antibiotics are administered during treatment and paracetamol is given after treatment if required for pain; soft and cold diet plus 0.12% chlorhexidine gluconate mouthwash for 5 days are prescribed in case of upper airway lesions. The first clinical follow-up with ultrasound and endoscopy was usually performed at 4 weeks after the procedure in all patients. In case of moderate volume reduction and/or persistence of symptoms, patients are recommended for a second injection that is usually performed 6-8 weeks after the first one. Finally, patients undergo physical and MRI radiological examination at 6 months following the last injection.
Sclerotherapy technique
The sclerosing solution used in this study was 3% POL microfoam (Polidocasklerol; Zeria Pharmaceutical Co, Ltd, Tokyo, Japan). The sclerosing foam was provided on-site by direct injection using a liquid to air ratio of 1:4. Two syringes were attached by a three-way stopcock, one filled with POL and the other with air; the foam was obtained by mixing the two syringes with multiple passages as described by Tessari 21.
Vascular malformations of upper aero-digestive airways were treated by endoscopic-guided trans-oral direct injection. Previous sedation or general anaesthesia, a 20-gauge venous catheter (JELCO PLUS; Smiths Medical Japan Ltd, Tokyo, Japan) was inserted into the lesion for no more than 1 cm (to make sure the right depth has been reached, plastic cover wrapping the distal portion of 1 cm from the extremity of the catheter was removed). The needle was placed into the lesion at the point of maximal deformation and then 3% POL-microfoam was injected after aspiration of part of the liquid contained within the lesion.
Cervical lesions (without involvement of aero-digestive airways) were treated by percutaneous procedures under local anaesthesia with ultrasound guidance. In these cases, 3% POL-microfoam was directly injected under ultrasound guidance with a 20-gauge needle with previous aspiration of an adequate amount of liquid contained within the lesion.
We performed all procedures in close collaboration with an interventional radiologist in order to share expertise and improve the precision during both ultrasound-guided and endoscopic-guided injection.
In case of macrocytic lesions a single injection is performed, while in other cases additional injections may be required. The volume injected depended on the size of the malformation and on the amount of aspirated content of the lesion. However, the maximum dose of injected sclerosant did not exceed 2 mg/kg of POL independently of the number of injections. The common pharmaceutical form of POL is a 2-mL 3% ampule for injection and contains 60 mg of POL. Hence, the maximum volume of POL liquid is 0.067 mL/kg. This means that the maximum volume of foam that can be provided from 3% POL by the Tessari method using a liquid to air ratio of 1:4 is 0.34 mL/kg.
Outcomes
Volumetric analysis was carried out by an expert head and neck radiologist using a workstation (Advanced Workstation 4.7®, GE Healthcare) with dedicated software (Volume Viewer®, GE Healthcare), evaluating pre- and post-procedural MRI studies. Lesion volume was calculated using semiautomatic segmentation with the summation-of-area technique. The lesion was manually segmented on all axial T2-weighted images and the software automatically reconstructed and calculated the volume 22,23.
The efficacy of the procedure was evaluated in terms of resolution of clinical symptoms and volume reduction by MRI comparing preoperative MRI lesion volume with that at 6 months. An excellent response was assumed if > 90%volume reduction and complete resolution of symptoms was observed; a moderate response was considered in case of 50-90% volume reduction and partial or complete resolution of symptoms; poor response was noted in case of < 50% volume reduction and partial or no resolution of symptoms. In our experience, the polidocanol was completely resorbed at the post treatment MRI at 6 months.
Our experience with polidocanol sclerotherapy began in 2016, and thus the maximum length of follow-up is 4 years, with a mean long-term follow-up of 34 months. We usually perform clinical ENT evaluation and ultrasound monitoring every year.
We also evaluated the safety, side effects, average length of stay and need for supportive medical treatment.
Statistical analysis
Clinical and demographic characteristics were described with descriptive statistics. In particular, the quantitative variables were represented by minimum, maximum, median, range, average and standard deviation (SD), and qualitative ones by absolute and percentage frequencies.
SPSS program version 25.0 (SPSS Inc; IL, USA) was used for statistical analysis. Continuous values such as volume of the lesions, were expressed as median and range. Volume reduction was express as mean ± SD. Baseline and post-treatment values were compared using Student’s test for paired samples in normally distributed values and Mann-Whitney U-test for non-normally distributed data. Results were considered significant for p < 0.05.
Results
Twenty patients were included in the analysis [8 females (40%); mean age 26.3 ± 14.4 years (range 7-60)] who underwent direct intra-lesional sclerotherapy with 3% POL microfoam; 7/20 (35%) were paediatric patients ≤ 18 years and 13/20 (65%) were adults. None had previously received surgical treatment or sclerotherapy with sclerosant agents. The lesions were classified based on the ISSVA classification as follow: 13/20 (65%) LMs and 7/20 (35%) VMs. LMs were macrocystic in 7/13 (53.8%), mixed in 5/13 (38.5%) and microcystic in 1/13 (7.7%). According to the de Serres staging system, 3/13 (23.1%) were stage I, 6/13 (46.1%) stage II, 3/13 (23.1%) stage III and 1/13 (7.7%) stage V.
Baseline characteristics of patients and anatomic localisation of the head and neck lesions are reported in Table I. Clinical characteristics for each patient are summarised in Table II. We treated 12 patients by a percutaneous procedure under ultrasound guidance and 8 patients by direct endoscopic injection as reported in Table III.
We observed a significant difference between pre-treatment mean MRI diameters [46.8 x 32.8 x 28.8 mm; cranio-caudal (CC), antero-posterior (AP), laterolateral (LL), respectively] versus post-treatment ones (31.3 x 21.5 x 17.5 mm; CC, AP, LL, respectively) (p < 0.05). The median pre-treatment volume evaluated by dedicated software was 20.58 mL (range 0.3 mL-436.8 mL) and decreased to 6.1 mL post-sclerotherapy (range 0.05 mL-176 mL) (p < 0.05). Finally, a mean volume reduction of 73.38% was observed considering all cases.
A subanalysis based on the type of lesion was performed. Preoperative median volume for VMs was 3.5 mL (range 0. 3mL-436.8 mL) and reduced post-operatively to 0.3 mL (range 0.05 mL-176 mL), with a mean volume reduction of 76.1% (p < 0.05). The median preoperative volume of LMs was 21.5 mL (range 0.96 mL-117 mL) and decreased post-treatment to 6.5 mL (range 0.08 mL-16.9 mL), with a mean volume reduction of 71.8% (p < 0.05). Considering the type of LM, we observed that the median volume reduction decreased from 19.6 mL (range 0.9 mL-117 mL) to 5.1 mL (range 0.08 mL-11.3 mL) (p < 0.05) in macrocystic LMs; from 21.5 mL (range 10.1 mL-21.5 mL) to 6.5 mL (range 3.5 mL-10.5 mL) (p < 0.05) in mixed LMs; from 29.3 mL to 16.9 mL in microcystic one. The volume reduction was 79.5% in macrocystic LMs, 67.1% in mixed LMs and 42.5% in the microcystic one.
In our series, the average amount of POL injected was 3.58 cc (3-10 cc) and general anaesthesia was required in 6/20 (30%) patients. The mean duration of hospitalisation was 1.15 days. Table III shows the effectiveness, safety and technical details of the procedures. In terms of effectiveness, we observed an excellent response in 9/20 (45%) patients, a moderate response in 10/20 (50%) and poor response in only 1 patient (5%). Figures 1, 2 and 3 show, respectively, a case of excellent response of a macrocystic LM of the floor of the mouth/submandibular region, a case of moderate response of rhino-oropharyngeal VM and a case of poor response of oro-hypopharyngeal microcystic LM.
According to the type of malformation, we observed the following responses: in macrocystic LMs an excellent response in 4/7 (57.1%) and a moderate one in 3/7 (42.9%); in mixed LMs, a moderate response in all cases (5/5); in the single treated microcystic LM, a poor response; in VMs, an excellent response in 3/7 (42.9%) and a moderate one in 4/7 (57.1%). Figures 4 and 5 show two cases of excellent response of the oral vestibule VM and tongue VM, respectively.
All patients who obtained an excellent response (7/20) achieved the result after a single session. In the remaining 13/20 (65%) patients, a second treatment was proposed, even if 5/13 (38.4%) patients refused because of clinical symptomatic improvement. Finally, 8/13 (61.6%) patients underwent a second injection and 7/13 (53.8%) obtained a moderate response and 1/13 (7.7%) patients had a poor one at 6-month follow-up.
At long-term follow-up, we did not observe relapse or re-growth of treated lesions confirming that our results were stable over time. Regarding the safety of polidocanol sclerotherapy, no complications were noted during any treatment session. One patient developed a significant pharyngeal swelling after the first injection that resolved in 2-3 days with oral steroids, two patients complained of a significant swelling of the parotid region after intra-lesional injection that resolved in 2-3 days with oral steroids and two patients referred moderate-severe pain after the procedure that resolved in one day with paracetamol. All other patients experienced only mild pain or mild oedema immediately after the procedure. No other complications such as intra-lesional bleeding, fever, secondary infections, or neurological deficits were observed.
Moreover, we never observed obstruction of upper aero-digestive airways after sclerotherapy.
Discussion
At present, there are no guidelines for the treatment of head and neck vascular malformations. Surgery remains the gold standard in most cases, although it is burdened by poor aesthetic and functional results. Nowadays, sclerotherapy has become a first-choice treatment, especially in low-flow vascular malformations (venous and lymphatic ones), because it is moderately invasive, well tolerated and effective.
Numerous sclerosing agents have been proposed over the years. Recently, microfoam injection has become increasingly popular thanks to its unique properties and ease of management. In particular, POL is a non-ionic surfactant sclerosing agent that can reduce the volume of malformation by directly damaging the vascular endothelial cells thanks to activation of cellular calcium signalling and nitric oxide pathways. The POL foam displaces blood instead of diluting in it, allowing strict control of the concentration of the agent in the vessel and leading to homogeneous distribution within the lumen. Ultrasound-guided microfoam POL sclerotherapy has been reported to be safe and effective for treatment of VMs 15. In a recent manuscript, Hou et al. 16 described their experience of POL sclerotherapy in 47 patients with VMs and reported a poor outcome for only 2/47 patients. POL sclerotherapy of LMs has been reported in only a few series and rarely in head neck lesions 14,17,24. Yamaki et al. 17 described a series of 32 LMs treated with polidocanol sclerotherapy. In that series, only 47% of cases had a head and neck localisation. The authors observed excellent and moderate responses in 88% of patients and concluded that polidocanol sclerotherapy should be considered in the treatment of LMs, particularly those that are exclusively macrocystic.
Jain et al. 13 reported a heterogenous series of vascular malformations treated with 1% polidocanol and observed an 80% or greater decrease in the volume of the lesion in the majority of patients; however, they did not further classify lymphangiomas based on dimension of the cysts. Blaise et al. 18 described a series of 24 cases of low-flow vascular malformations treated with polidocanol (only 9 were located in the head and neck region), reporting > 50% reduction in 37.5% of cases and < 50% reduction in 58.3% of cases.
All studies have confirmed the excellent safety of POL sclerotherapy even if there is some disagreement in terms of effectiveness. This discrepancy is justified by the rarity and significant heterogeneity of vascular malformation in terms of the location, type and dimension. In this series, we describe a series of exclusively head and neck vascular malformations, including upper airway lesions, demonstrating that POL sclerotherapy is an effective and safe procedure both for VMs and LMs. In fact, at 6 months follow-up we observed a mean MRI volume reduction of 73.38% in the entire series. We observed an excellent response in one single injection in 35% of patients, and a moderate response in 60% of patients with one or two injections. Overall, an excellent-moderate response was observed in 95% of cases. The number of treatment sessions required using POL in our series is comparable to that of other agents 7. Regarding morbidity of the procedure, we observed only mild side effects that were easy to manage in the early post-operative period. Finally, at long-term follow-up, we observed that our results were stable over time. We believe that one factor contributing to the high success rate is our radiologist-ENT multidisciplinary approach that is extremely beneficial in the management of these patients in both the pre-treatment setting to characterise the lesion and during the procedure to maximise outcomes. Cooperation is particularly important in the pre-treatment setting in order to identify the best candidate for sclerotherapy, and the optimal time to proceed. Decision to treat in fact is based not only on functional and aesthetic concerns, but also on radiologically documented increases in dimensional lesion.
This study should be interpreted in the context of its strengths and limitations. The strength of our study lies in the homogeneity of treatment strategy: in fact, it is a single-centre study, thus ensuring homogeneity in technique and patient care. All patients received the same procedure, and all patients were required to undergo MRI before treatment and at 6 months after the last injection. None of the lesions had been previously treated and all lesions were localised in the head and neck region. To best of our knowledge, this is one of the larger case series of low flow vascular malformations of head and neck treated with POL foam sclerotherapy. We also performed a subanalysis for type of malformation, observing better responses in head and neck macrocystic LMs and VMs. Furthermore, in agreement with literature data, we observed a moderate response in all mixed LMs and a poor response in microcystic LMs. Finally, we confirmed the safety and effectiveness of the endoscopic-guided intralesional injection of sclerosing agent for treatment of upper airway malformations, firstly described in a small case series 25. The limits of this study are related to its retrospective design and the lack of standardised method for evaluation of symptoms.
Conclusions
Our data suggest that polidocanol sclerotherapy, performed in cooperation with a radiologist and otolaryngologist, is an effective and safe procedure in cases of head and neck venous malformations and macrocystic lymphatic ones, and provided very good results in mixed lymphatic malformations as well. These promising results should be confirmed by further and larger prospective studies in order to establish the best indications for this agent.
Conflict of interest statement
The authors declare no conflict of interest.
Funding
This research did not receive any specific grant from funding agencies in the public, commercial, or not-for-profit sectors.
Authors’ contributions
Conceptualization: EDC; methodology: GS and GDC; validation: EDC; formal analysis: AC, SG and MP; investigation: SG, MP, AC, GS and GDC; data curation: EDC and GDC; writing – original draft preparation: EDC and GDC; writing –review and editing: EDC and GDC; supervision: CC and GP; project administration: EDC and GDC. All authors have read and agreed to the published version of the manuscript.
Ethical consideration
This study was approved by the Institutional Ethics Committee (Fondazione Policlinico Universitario Agostino Gemelli IRCCS) [Approval Number/Protocol Number 11142/20 (ID3035)].
The research was conducted ethically, with all study procedures being performed in accordance with the requirements of the World Medical Association’s Declaration of Helsinki.
Written informed consent was obtained from each participant/patient for study participation and data publication.
Figures and tables
Case series | N = 20 |
---|---|
Demographics | |
Age | 26.85 ± 14.4 DS (range 7-60) |
Female | 8/20 (40%) |
Male | 12/20 (60%) |
Vascular malformations | |
Venous malformations | 7/20 (35%) |
Lymphatic malformations (LMs) | 13/20 (65%) |
Macrocystic LMs | 7/13 (53.8%) |
Mixed LMs (Macrocystic and Microcystic) | 5/13 (38.5%) |
Microcystic LMs | 1/13 (7.7%) |
Anatomic distribution | |
Lateral neck region | 4/20 (20%) |
Oropharynx | 3/20 (15%) |
Oral cavity | 4/20 (20%) |
Parotid - parapharyngeal space | 2/20 (10%) |
Parotid - masticatory space | 3/20 (15%) |
Submandibular-floor of the mouth | 3/20 (15%) |
Eyelid | 1/20 (5%) |
Case | Sex, age | Site | Symptoms | Type of vascular malformation | de Serres 20 staging system for LMs |
---|---|---|---|---|---|
1 | F, 19 | Lateral neck region | Swelling | Macrocystic LM | I |
2 | M, 18 | Parotid – Parapharyngeal space | Bleeding | Macrocystic LM | II |
3 | F, 15 | Submandibular – Floor of the mouth | Swelling | Mixed LM | II |
4 | M, 28 | Lateral neck region | Swelling | Macrocystic LM | I |
5 | M, 38 | Submandibular – Floor of the mouth | Swelling | Macrocystic LM | III |
6 | F, 30 | Lateral neck region | Swelling | Mixed LM | III |
7 | M, 24 | Oropharynx – Hypopharynx | Swallowing | Microcystic LM | V |
8 | M, 25 | Pharynx | Swallowing | VM | NA |
9 | M, 22 | Tongue – Floor of the mouth | Swallowing | Macrocystic LM | II |
10 | M, 26 | Oropharynx | Globus | Macrocystic LM | III |
11 | M, 18 | Oral Vestibule | Bleeding | VM | NA |
12 | M, 35 | Parotid – Masticatory space | Pain at mastication | Mixed LM | II |
13 | M, 8 | Parotid – Masticatory space | Pain at mastication | VM | NA |
14 | F, 60 | Tongue – Lips – Temporal region | Impaired mastication | VM | NA |
15 | M, 17 | Lateral neck region | Infection, Swelling | Macrocystic LM | I |
16 | F, 7 | Parotid – Pharyngeal space | Swallowing, Pain | VM | NA |
17 | F, 26 | Eyelid | Ptosis | VM | NA |
18 | F, 58 | Tongue | Impaired mastication | VM | NA |
19 | F, 15 | Parotid – Masticatory space | Swelling | Mixed LM | II |
20 | M, 48 | Submandibular – Floor of the mouth | Swelling | Mixed LM | II |
Case | MRI pre dimension dCCxLLxAP | MRI post dimension dCCxLLxAP | % volume reduction | Symptom resolution | Anaesthesia | Guidance | No. sessions | Complications | Outcome |
---|---|---|---|---|---|---|---|---|---|
1 | 64x33x23 | 41x22x11 | -79.6% | Complete | L | US | 2 | No | Moderate |
2 | 53x43x15 | 41x30x11 | -60.4% | Complete | L | US | 2 | Swelling | Moderate |
3 | 15x34x38 | 11x24x26 | -64.6% | Partial | L | US | 2 | Pain | Moderate |
4 | 45x31x20 | 22x11x10 | -91.3% | Complete | L | US | 1 | No | Excellent |
5 | 50x33x36 | 26x14x16 | -90.2% | Complete | L | US | 1 | No | Excellent |
6 | 43x37x26 | 36x28x20 | -51.3% | Partial | L | US | 2 | No | Moderate |
7 | 47x40x30 | 39x32x26 | -42.5% | None | G | Endoscopy | 2 | No | Poor |
8 | 100x32x27 | 84x23x21 | -53% | Partial | G | Endoscopy | 2 | Swelling | Moderate |
9 | 12x11x14 | 8x5x4 | -91.3% | Complete | L | Endoscopy | 1 | No | Excellent |
10 | 42x30x30 | 32x24x23 | -53.3% | Partial | G | Endoscopy | 2 | Pain | Moderate |
11 | 11x24x20 | 5x11x9 | -90.6% | Complete | L | Transoral/US | 1 | No | Excellent |
12 | 35x31x43 | 26x24x26 | -65.2% | Partial | L | US | 1 | No | Moderate |
13 | 37x33x30 | 29x24x18 | -65.8% | Partial | G | US | 1 | Swelling | Moderate |
14 | 30x16x12 | 12x7x6 | -91.3% | Complete | G | Transoral/US | 1 | No | Excellent |
15 | 76X40X74 | 34x20x32 | -90.3% | Complete | L | US | 1 | No | Excellent |
16 | 140x100x60 | 94x75x48 | -59.7% | Partial | G | Transoral/US | 2 | Pain | Moderate |
17 | 16x7x5 | 12x4x2 | -82.9% | Complete | L | US | 1 | No | Moderate |
18 | 28x16x15 | 12x9x6 | -90.4% | Complete | L | Transoral/US | 1 | No | Excellent |
19 | 51x47x80 | 39x26x37 | -80.5% | Complete | L | US | 1 | No | Moderate |
20 | 41x32x33 | 31x22x17 | -73.2% | Complete | L | US | 1 | No | Moderate |
References
- Wassef M, Blei F, Adams D. Vascular anomalies classification: recommendations from the International Society for the Study of Vascular Anomalies. Pediatrics. 2015; 136:e203-214. DOI
- Classification International Society for the Study of Vascular Anomalies.Publisher Full Text
- Nosher JL, Murillo PG, Liszewski M. Vascular anomalies: a pictorial review of nomenclature, diagnosis and treatment. World J Radiol. 2014; 6:677-692. DOI
- Tasnádi G. Epidemiology and etiology of congenital vascular malformations. Semin Vasc Surg. 1993; 6:200-203.
- Ballah D, Cahill AM, Fontalvo L. Vascular anomalies: what they are, how to diagnose them, and how to treat them. Curr Probl Diagn Radiol. 2011; 40:233-247. DOI
- Espinel AG, Bauman NM. Psychosocial impact of vascular anomalies on children and their families. Otolaryngol Clin North Am. 2018; 51:99-110. DOI
- Horbach SER, Lokhorst MM, Saeed P. Sclerotherapy for low-flow vascular malformations of the head and neck: a systematic review of sclerosing agents. J Plast Reconstr Aesthetic Surg. 2016; 69:295-304. DOI
- De Maria L, De Sanctis P, Balakrishnan K. Sclerotherapy for venous malformations of head and neck: systematic review and meta-analysis. Neurointervention. 2020; 15:4-17. DOI
- Ierardi AM, Colletti G, Biondetti P. Percutaneous sclerotherapy with gelified ethanol of low-flow vascular malformations of the head and neck region: preliminary results. Diagn Interv Radiol. 2019; 25:459-464. DOI
- Greinwald JH, Burke DK, Sato Y. Treatment of lymphangiomas in children: an update of Picibanil (OK-432) sclerotherapy. Otolaryngol Head Neck Surg. 1999; 121:381-387. DOI
- Parashar G, Shankar G, Sahadev R. Intralesional sclerotherapy with bleomycin in lymphatic malformation of tongue an institutional experience and outcomes. J Indian Assoc Pediatr Surg. 2020; 25:80-84. DOI
- Cheng J. Doxycycline sclerotherapy in children with head and neck lymphatic malformations. J Pediatr Surg. 2015; 50:2143-2146. DOI
- Jain R, Bandhu S, Sawhney S. Sonographically guided percutaneous sclerosis using 1% polidocanol in the treatment of vascular malformations. J Clin Ultrasound. 2002; 30:416-423. DOI
- Wang L, Liu F, Huang S. Percutaneous lauromacrogol foam sclerotherapy for the treatment of acute airway compression caused by lymphatic malformations in infants. Biomed Res Int. 2018; 2018:3878960. DOI
- Grieb D, Meila D, Greling B. Craniofacial venous malformations treated by percutaneous sclerotherapy using polidocanol: a single-center experience. Acta Radiol Stockh Swed. 2019; 60:593-601. DOI
- Hou F, Chen J, Xia M. Percutaneous sclerotherapy with polidocanol under the guidance of ultrasound for venous malformations in children - A retrospective cohort study from a single tertiary medical center. Medicine (Baltimore). 2020; 99:e18839. DOI
- Yamaki T, Sasaki Y, Hasegawa Y. Percutaneous ultrasound-guided sclerotherapy with polidocanol microfoam for lymphatic malformations. J Vasc Surg Venous Lymphat Disord. 2017; 5:707-714. DOI
- Blaise S, Charavin-Cocuzza M, Riom H. Treatment of low-flow vascular malformations by ultrasound-guided sclerotherapy with polidocanol foam: 24 cases and literature review. Eur J Vasc Endovasc Surg. 2011; 41:412-417. DOI
- Warren TA, Gandhi M, Panizza B. Pictorial review: vascular anomalies of the head and neck. J Med Imaging Radiat Oncol. 2012; 56:84-92. DOI
- de Serres LM, Sie KC, Richardson MA. Lymphatic malformations of the head and neck. A proposal for staging. Arch Otolaryngol Head Neck Surg. 1995; 121:577-582. DOI
- Tessari L, Cavezzi A, Frullini A. Preliminary experience with a new sclerosing foam in the treatment of varicose veins. Dermatol Surg. 2001; 27:58-60.
- Knegjens JL, Hauptmann M, Pameijer FA. Tumor volume as prognostic factor in chemoradiation for advanced head and neck cancer. Head Neck. 2011; 33:375-382. DOI
- Lodder WL, Gilhuijs KGA, Lange CAH. Semi-automated primary tumor volume measurements by dynamic contrast-enhanced MRI in patients with head and neck cancer. Head Neck. 2013; 35:521-526. DOI
- Markovic JN, Nag U, Shortell CK. Safety and efficacy of foam sclerotherapy for treatment of low-flow vascular malformations in children. J Vasc Surg Venous Lymphat Disord. 2020; 8:1074-1082. DOI
- Oomen KP, Paramasivam S, Waner M. Endoscopic transmucosal direct puncture sclerotherapy for management of airway vascular malformations. Laryngoscope. 2016; 126:205-211. DOI
